Horizontal clamp DHQA

  • Clamp for horizontal movement of a sheet.
  • Safety factor: 4: 1.
  • Material of manufacture: high strength steel.
  • Coating: painting.
  • Standard: EN 13155: 2018.
  • It is accompanied by a quality certificate.
  • Warranty: 12 months.


More details

Select attributes:

Price:

1 563,61 грн.

Horizontal clamp is used for lifting and moving sheet metal. When lifting, clamps are usually applied in pairs. Horizontal clamp meets the modern standard EN 13155: 2018. All clamps are mandatory tested at the stand, accompanied by a passport and a guarantee.

For the convenience of engaging the clamp with a hook of the sling, we recommend that you complete the clamp with a lifting shackle.

Note!

Standard cargo clamps have a minimum load limit of 10% of the maximum load capacity indicated on the clamp body. In simple words - it will not work to lift clamps with a working load of 2 tons, a sheet of metal weighing less than 200 kg. The capture tongue will not be able to securely fix the sheet and in this case the sheet will bend, spring and pop out of the clamp.

Захват горизонтальныйДопустимая нагрузка при различных углах ветви стропа

Carrying capacity, t

(one clamp)

Jaw, мм

S, мм

H, мм

L, мм

Weight,

kg

2.00

0-50

27

13

10

6.0

3.00

5-60

30

18

17

8.5

4.50

10-80

32

18

18

12.6
