Polypropylene endless sling

Polypropylene endless sling

  • Material: Polypropylene;
  • Safety factor: 7: 1;
  • Temperature range of application: from -40 to +100 ° C;
  • Standard: EN 1492-4:2018;
  • Slings are made by braiding;
  • Warranty: 3 months.
  • Manufacturer: LTD LOAD-TECH, Ukraine Украина

More details

Select attributes:

Price:

272,50 грн.

Polypropylene rope slings are used for lifting and moving various loads. The main scope of use is construction and industrial enterprises and is also widely used in offshore operations. Fiber rope slings are flexible, hold well and do not spoil the surface of the load.


Polypropylene sling is distinguished by high resistance to bending, good strength, does not sink in water. The sling is practically not susceptible to decay, the harmful effects of the environment, sea water. However, it should be noted that the polypropylene sling is quite electrified, unstable to sunlight and abrasion. The elongation of the sling under load can be up to 12% of the initial length.

Polypropylene slings are slightly affected by acids and alkalis, but are damaged by some solvents, resins and paints.



Benefits:

 • low dead weight;

• safety (do not injure the slinger due to the low weight and the absence of sharp burrs and protruding wires as in rope slings);

• compactness, flexibility, elasticity (easy to fold, occupying a minimum volume, and most importantly, also easily take their original form after unpacking);

• do not damage fragile and delicate goods;



Disadvantages:

• easily damaged by sharp edges of the load;

• are operable only strictly in temperature conditions from -40 to +100 ° C.



 ATTENTION! Basic rules for working with slings:

• Before using the sling, check the maximum passport lifting capacity of the sling with the actual weight of the load lifted;

• Use slings strictly in accordance with their carrying capacity;

• Do not use slings with damage or defects;

• Do not use slings at ambient temperatures below -40 ° C and above +100 ° C;

• Slings should be kept dry and clean, away from heat and direct sunlight;











Rope diameter,

WLL Working Load Limit


Direct lift


Tightening


Basket lift


Parallel lift



эскиз


               Эскиз



эскиз



 эскиз



                мм

                                        Carrying capacity, t


M= 1, т


M = 0,8, т



        M =1,4          Р=0°<45°



M = 2

          16

0,96

0,76

1,3

            1,9

18

1,2

0,96

1,7

     2,4

          20

1,5

1,2

2,0

     3,0

22

1,8

1,4

2,6

     3,6

24

2,2

1,8

3,0

     4,4

26

2,4

1,9

3,4

     4,8

          28

2,8

2,2

4,0

     5,6

30

3,0

2,4

4,2

     6,0

          32

3,4

2,8

4,8

     6,8

          36

4,4

3,6

6,2

     8,8

          40

5,2

4,2

7,2

     10,4

          44

6,4

5,2

9,0

     12,8

          48

7,4

6,0

10,4

     14,8



You can buy polypropylene slings in our stores in Odessa, Kiev and Kharkov, or order delivery anywhere in Ukraine.
